Jendela Geser Paduan Aluminium

Yehaoxuan Aluminum Alloy Sliding Windows utilize a multi-track pulley design for smooth and quiet operation. They come standard with multiple seals and a hidden drainage system.  Customizable opening methods, glass configurations, and surface colors are available.  They are suitable for various applications, including commercial building facades, high-end residential balconies/floor-to-ceiling windows, and office space partitions, balancing architectural aesthetics and practical functionality while complying with building energy efficiency and safety regulations.

1. Rangka Kuat, Stabil dan Tahan Cuaca

Rangka utama Jendela Geser Paduan Aluminium menggunakan profil paduan aluminium presisi tinggi 6063-T5. Ketebalan dinding profil disesuaikan sesuai kebutuhan (memenuhi spesifikasi teknik dinding tirai).  Proses pemotongan dan penyambungan sudut CNC yang presisi memastikan struktur yang stabil dan ketahanan tekanan angin yang sangat baik, mampu menahan angin kencang. Permukaannya diperlakukan dengan penyemprotan fluorokarbon, pelapisan bubuk, dan proses pencetakan transfer butiran kayu, memberikan ketahanan terhadap sinar UV, ketahanan terhadap hujan asam, dan ketahanan terhadap korosi.  Ini tidak akan pudar atau teroksidasi selama penggunaan di luar ruangan, beradaptasi dengan iklim regional yang berbeda sekaligus memastikan estetika dan daya tahan jangka panjang.

2. Kaca Berkualitas Tinggi, Hemat Energi dan Aman

Standard configuration includes double-glazed tempered glass, with options for Low-E double-glazed glass, laminated tempered glass, and double-glazed laminated composite glass. Glass thickness is customizable to meet different sound insulation, heat insulation, and explosion-proof requirements. Low-E double-glazed glass effectively blocks ultraviolet rays and heat transfer, reducing building energy consumption; laminated glass prevents shattering and scattering upon breakage, enhancing safety. All glass is 3C certified and meets building safety standards, balancing natural light transmission and energy-saving protection.

3. Rekayasa Presisi, Halus dan Tahan Lama

Yehaoxuan Aluminum Alloy Sliding Windows utilize a multi-track silent pulley design. The pulleys are made of stainless steel/nylon, offering strong load-bearing capacity and smooth sliding.  Operation is smooth and quiet, with low noise and excellent wear resistance and anti-aging properties, ensuring a long service life. Customizable single-track, double-track, and triple-track opening options are available, supporting left-right and up-down sliding.  The flexible opening allows for adjustable ventilation area, adapting to the ventilation and usage needs of different spaces.  Multiple EPDM sealing strips are used between the frame and glass for a tight fit, enhancing sound insulation, waterproofing, and dustproof performance.

4. Desain Rinci, Peningkatan Praktis

Standard features include a hidden drainage system with a stepped drainage structure for rapid rainwater drainage, preventing water accumulation and leakage, and improving waterproofing performance. High-end custom hardware is used, with user-friendly lock points and handles for convenient operation, and is rust-proof and durable. Screens (diamond mesh screens/invisible screens) can be added as needed, combining ventilation with mosquito and theft protection.  Customizable opening and fixed position ratios are supported, adapting to the overall design of the building facade, achieving a balance of practicality and aesthetics.

5. Adaptasi Khusus, Aplikasi Universal

Aluminium Alloy Sliding Windows mendukung kustomisasi personalisasi dimensi penuh.  Spesifikasi keseluruhan dinding tirai, cara bukaan, konfigurasi kaca, ketebalan dinding profil, dan warna permukaan semuanya dapat disesuaikan dengan dimensi bangunan. Pilihan warnanya antara lain hitam matte, emas sampanye, coklat tua, dan serat kayu, menyesuaikan dengan berbagai gaya arsitektur seperti minimalis modern, kemewahan ringan, dan gaya Cina baru. Desain modular memudahkan pemasangan dan cocok untuk fasad, balkon, jendela setinggi langit-langit, dan partisi interior kompleks komersial, gedung perkantoran, hunian kelas atas, dan vila, melayani dekorasi arsitektur dan optimalisasi fungsi ruang.

Pertanyaan Umum

1. Apa bahan rangka inti dinding tirai jendela geser, dan apa persyaratan ketebalan dinding?

Rangka utama terbuat dari profil paduan aluminium presisi tinggi 6063-T5. Ketebalan dinding profil disesuaikan dengan spesifikasi teknik dinding tirai untuk memenuhi persyaratan ketahanan tekanan angin di berbagai ketinggian dan wilayah bangunan, memastikan struktur yang stabil dan patuh.

2. Konfigurasi kaca apa yang tersedia untuk jendela geser, dan kebutuhan apa yang dipenuhi masing-masing jendela tersebut?

Konfigurasi standar mencakup kaca tempered berlapis ganda bersertifikasi 3C. Opsi opsional mencakup kaca berlapis ganda Low-E (hemat energi, insulasi panas, dan pemblokiran UV), kaca tempered laminasi (tahan ledakan dan anti pecah), dan kaca komposit laminasi berlapis ganda (hemat energi + tahan ledakan). Ketebalan kaca dapat disesuaikan dengan kebutuhan.
